GF7025-M2
32
CPU Smart Fan
T his item allows you to control the CPU Fan.
The Choices: Disabled (default), Auto, 4-pin, 3-pin..
Smart Fan Calibration
Choose this item and then the BIOS will auto test and detect the CPU fan
functions and show CPU fan speed.
PWM Duty Off<℃>
If the CPU Temperature is lower than the set value, FAN will turn off.
The Choices: Min=0,.Max=127, Key in a DEC number.
PWM Duty Start<℃>
CPU fan starts to work under smart fan function when arrive this set
value.
The Choices: Min=0,.Max=127, Key in a DEC number.
Start PWM Value
When CPU temperature arrives to the set value, the CPU fan will work
under Smart Fan Function mode. The range is from 0~127, with an
interval of 1.
The Choices: Min=0,.Max=127, Key in a DEC number.
Smart Fan Slope
Increasing the value of s lope PWM will raise the speed of CPU fan.
The Choices: Min=1,.Max=127, Key in a DEC number.
Shutdown Temperature
This item allows you to set up the CPU shutdown Temperature. This item is
only effective under Windows 98 ACPI mode.
The Choices: Disabled , 60℃/ 140℉, 65℃/ 149℉, 70℃/ 158℉, 75℃/ 167℉,
80℃/ 176℉(default), 85℃/ 185℉, 90℃/ 167℉.
Show H/W Monitor in POST
If you computer contains a monitoring system, it will show PC health status
during POST stage. The item offers several different delay times.
The Choices: Enabled (default), Disabled.
