GF7025-M2
36
Memory Hole Remapping
The Choices: Enabled (default), Disabled.
Auto Optimize Bottom IO
The Choices: Enabled (default), Disabled.
Bottom of [31:24] IO space
The Choices: C0 (default); Min=0000, Max=00FF, key in a HEX number.
Bottom of UMA DRAM [31:24]
The Choices: FC (default); Min=0000, Max=00FC, key in a HEX number.
PCIE Clock
This item allows you to select the PCIE clock.
The Choices: 100Mhz (default), 101Mhz~150Mhz.
