Biostar H610MH User Manual

4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Support for 12/13th Generaon Intel® Core™ i9/ i7/ i5/ i3 processors and Intel® Penum® processors/
Intel® Celeron® processors in the LGA1700 package
* Please refer to www.biostar.com.tw for CPU support list.
Chipset Intel® H610
Memory
Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666/ 2933/ 3200
2x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
Each DIMM supports non-ECC 4/8/16/32GB DDR4 module
Support Intel® Extreme Memory Prole (XMP) memory modules
* Please refer to www.biostar.com.tw for Memory support list.
Storage
-- Total supports 1x M.2 socket and 4x SATA III (6Gb/s) ports
4x SATA III Connector (6Gb/s)
1x M.2 (M Key) Socket (M2_PCIEG3_32G_ SATA):
Supports M.2 Type 2240 /2260 /2280 SSD module
Supports PCIe 3.0 x4 (32Gb/s) - NVMe/ AHCI SSD & SATA SSD
LAN
H610MX-E / H610MX / H610MH-E / H610MH /
H610MHP / H610MHC
Intel i219v
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex
capability
H610MX2-E / H610MH2 / H610MHP2
Realtek RTL8125B
10/ 100/ 1000/ 2500 Mb/s auto negoaon, Half / Full
duplex capability
Audio Codec
ALC897
7.1 Channels, High Denion Audio
USB
4x USB 3.2 (Gen1) port (2 on rear I/Os and 2 via internal headers)
8x USB 2.0 port (4 on rear I/Os and 4 via internal headers)
Expansion Slots
Intel 12th/13th Processors
1x PCIe 4.0 x16 Slot
Intel H610 Chipset
1x PCIe 3.0 x1 Slot
Rear I/Os
H610MX-E / H610MX2-E
1x WIFI Antenna Port
1x PS/2 Keyboard/ Mouse Port
1x HDMI
1x VGA+DVI Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack
H610MH-E
1x WIFI Antenna Port
1x PS/2 Keyboard/ Mouse Port
1x HDMI
1x VGA Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack
H610MX
1x PS/2 Keyboard/ Mouse Port
1x HDMI
1x VGA+DVI Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack
H610MH / H610MHP / H610MHC / H610MH2 / H610MHP2
1x PS/2 Keyboard/ Mouse Port
1x HDMI
1x VGA Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack

Biostar H610MH Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors	1
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1867, 2133, 2400, 2666, 2933, 3200 MHz
Supported memory module capacities	4GB, 8GB, 16GB, 32GB
Supported storage drive interfaces	M.2, SATA III
HDCP	Yes
DirectX version	12.0
Parallel processing technology support	-
BIOS type	UEFI
Number of SATA III connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel® I219-V
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel H610
PC health monitoring	CPU, FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	236 mm
Width	208 mm
