K8M800-M7A
1
CHAPTER 1: INTRODUCTION
1.1 MOTHERBOARD FEATURES
CPU
Supports Socket 754.
Supports AMD Athlon 64 processor up to 3700+.
Supports AMD Sempron processor.
Supports HyperTransport Technology up to 1600MT/s.
Chipset
North Bridge: VIA K8M800.
South Bridge: VIA VT8237R/VT8237R PLUS.
Dimensions
Micro ATX Form Factor: 18.999cm (W) x 24.384cm (L)
Operating System Supporting
Supports Windows 98 / Me / 2000 / XP / 64-bit.
Slot
Three 32bit PCI bus master slots.
One AGP 4x/8x compatible slot.
One CNR slot.
On-board IDE
Two on-board connectors support 4 IDE disk drives.
Supports PIO mode 0~4.
Supports Ultra DMA 33/ 66/100/133 Bus Master Mode.
System Memory
Supports up to 2 DDR devices.
Supports DDR-266/333/400.
Maximum memory size is up to 2GB. (Following table is only for
reference.)
DIMM Socket
Location
DDR Module Total Memory Size
DIMM1 128MB/256MB/512MB/1GB *1
DIMM2 128MB/256MB/512MB/1GB *1
Max is 2 GB.
