1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2
AMD Sempron processors
Supports Hyper Transport and Cool=n=Quiet
FSB Support HyperTransport Supports up to 800MHz Bandwidth
Chipset
K8M800
VT8237R+
Super I/O
ITE IT8705
Provides the most commonl
y
us e d l e
g
ac
y
Super I/O functionalit y.
Low Pin Count Interface
Environment Control initiatives,
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
Main
Memory
DIMM Slots x 2
Eac h DIMM supports 256/512MB & 1GB
DDR2
Max Memory Capicity 2GB
Dual Channel Mode DDR2 memory module
Supports DDR2 400 / 533 / 667
Registered DIMM and ECC DIMM is not supported
Graphics Integrated in K 8M800 Chips et M ax Shared V ideo Memory is 64MB
IDE
Integrated IDE Controller
Ultra DMA 33 / 66 / 100 / 133 Bus Maste
r
Mode
supports PIO Mode 0~4,
SA TA
Integrated Serial ATA Controller
Data transfer rates up to 1.5 Gb/s.
SATA Version 1.0 specification compliant.
LAN Realtek RTL8201CL 10 / 100 Mb/s Auto-Negotiation
Sound ALC655/ALC658 5.1 channels audio out
AGP slot x1 Supports AGP expansion cards
Slots
PCI slot x2 Supports PCI expansion cards
Floppy connector x1 Each connector supports 2 Floppy drives
IDE Connector x2 Each connector supports 2 IDE device
SATA Connector x2 Each connector supports 1 SATA devices
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CD-in Connector x1 Supports CD audio-in function
S/PDIF out connector x1 Supports digital audio out function
CPU Fan header x1 CPU Fan power supply (with Smart Fan function)
System Fan header x1 System Fan Power supply
CMOS clear header x1 Restore CMOS data to factory default
On Board
Connector
USB connector x2 Each connector supports 2 front panel USB ports

Biostar K8M800 MICRO AM2 Specifications

General

Brand	Biostar
Model	K8M800 MICRO AM2
Category	Motherboard
Language	English
