Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
JKBMS1
JCOM1
JVGA1
JUS B1
JUSBLAN 1
JAUDIO1
Super I/ O
Codec
JCDIN1 JSP DI F_OUT1 J SFAN 1 J U SB3JUSB2 JPANEL1
J SATA2
JS ATA1
JCMOS1
BAT1
IDE1
IDE2
JATX PW R1
FDD1
DIMMA1
DIMMB1
Socket A M2
K8M800
JPRNT1
LAN
PCI1
PCI2
BIOS
AGP 1
JATXP WR2
JAUDIO2
VT8237R+
JCFAN1
No te: ■ represents the 1
st
pin.
