Biostar M7VIG PRO User Manual

M
M
M
o
o
o
t
t
t
h
h
h
e
e
e
r
r
r
b
b
b
o
o
o
a
a
a
r
r
r
d
d
d
D
D
D
e
e
e
s
s
s
c
c
c
r
r
r
i
i
i
p
p
p
t
t
t
i
i
i
o
o
o
n
n
n
8
Front USB Header: JUSB2/ JUSB3
5V/ 5VSB Selection for USB: JUSBV1
CPU Frequency Selection: JCLK1
5V/ 5VSB Selection for Keyboard: JKBV1
JUSB2/3
2
1
Pin1,2 ==> +5V
Pin3,4 ==> Data(-)
Pin5,6 ==> Data(+)
Pin7,8 ==> Ground
Pin9 ==> KEY
Pin10 ==> NA
1
JKBV1
Pin 1-2 on ==> 5V
Pin 2-3 on ==> 5V_SB
1
JUSBV1
Pin 1-2 on ==> 5V
Pin 2-3 on ==> 5V_SB
1
JCLK1
On ==> 100MHz
Off ==> 133MHz
