Biostar MCP6P-M2 User Manual

MCP6P-M2
23
RAID 0+1:
RAID 0 drives can be mirrored using RAID 1 techniques. Resulting in a RAID 0+1
solution for improved performance plus resiliency.
Features and Benefits
 Drives: Minimum 4, and maximum is 6 or 8, depending on the platform.
 Benefits: Optimizes for both fault tolerance and perf ormance, allowing for
automatic redundancy. May be simultaneously used with other RAID levels
in an array, and allows for spare disks.
 Drawbacks: Requires twice the available disk space f or data redundancy,
the same as RAID level 1.
 Fault Tolerance: Yes.
Block 2
Block 4
Block 6
Block 1
Block 3
Block 5
Block 2
Block 4
Block 6
Block 1
Block 3
Block 5
nForce
6100-430

Biostar MCP6P-M2 Specifications

General

Form Factor	Micro ATX
CPU Socket	AM2
Memory Type	DDR2
Maximum Memory	4GB
Storage Interface	SATA, IDE
SATA	4 x SATA 3Gb/s
IDE	1 x IDE
Audio Chipset	Realtek ALC662
Audio Channels	6-Channel
LAN Chipset	Realtek RTL8201CL
Max. LAN Speed	10/100Mbps
PS/2	1 x PS/2 Keyboard, 1 x PS/2 Mouse
CPU Type	AMD Athlon 64 X2 / Athlon 64 / Sempron
Memory Slots	2
Expansion Slots	1 x PCI-E x16 1 x PCI-E x1 2 x PCI
USB Ports	4 x USB 2.0
