TA970
9
B. Memory Capacity
DIMM Socket
Location
DDR3 Module
Total Memory Size
DDR3_A1 512MB/1GB/2GB/4GB/8GB/16GB
DDR3_A2 512MB/1GB/2GB/4GB/8GB/16GB
DDR3_B1 512MB/1GB/2GB/4GB/8GB/16GB
DDR3_B2 512MB/1GB/2GB/4GB/8GB/16GB
Max is 64GB.
C. Dual Channel Memory Installation
Please refer to the following requirements to activate Dual Channel function:
Install memory module of the same density in pairs, shown in the table.
Dual Channel Status DDR3_A1 DDR3_A2 DDR3_B1 DDR3_B2
Enabled X O X O
Enabled O O O O
(O means memory installed, X means memory not installed.)
Note1: The DRAM bus width of the memory module must be the same (x8 or x16)
Note2: Memory module must be installed in DDR3-A2 or DDR3-B2 to boot the system.
D. DDR Speed Support
Please refer to the following table for DDR speed reference:
DDR Speed (1.5V)
# of DIMM per Channel
DDR3-1333 DDR3-1600 DDR3-1866
1 of 2 UDIMMs O O O
2 of 2 UDIMMs O O X
