TA970
3
SPEC
Serial Port Connector x1 Connects to RS-232 Port
Power Connector (24-Pin) x1 Connects to Power supply
Power Connector (4-Pin) x1 Connects to Power supply
Back Panel
I/O
PS/2 Keyboard x1
PS/2 Mouse x1
LAN port x1
USB2.0 Port x6
USB3.0 Port x2
Audio Jack x6
Connects to PS/2 Keyboard
Connects to PS/2 Mouse
Connect to RJ-45 ethernet cable
Connect to USB2.0 devices
Connect to USB3.0 devices (by Asmedia ASM1042 A4)
and USB2.0/USB1.X devices (by SB950)
Provide Audio-In/Out and Mic. connection
Board Size
305 mm (L) x 225 mm (W) ATX
OS Support
Windows XP / Vista / 7/ 8
Biostar reserves the right to add or remove support for any
OS With or without notice.
1.4 Rear Panel Connectors
