8
2.3 INSTALLING SYSTEM MEMORY
DDR2A1 DDR2B1 DDR2B2 DDR2A2
1. Unlock a DIMM slot by pressing the retaining clips outward. Align a
DIMM on the slot such that the notch on the DIMM matches the
break on the Slot.
2. Insert the DIMM vertically and firmly into the slot until the retaining
chip snap back in place and the DIMM is properly seated.
B. Memory Capacity
DIMM Socket
Location
DDR/DDR2 Module Total Memory Size
DDR2A1 256MB/512MB/1GB *1
DDR2B1 256MB/512MB/1GB *1
Max is 2GB.
DDR2A2 256MB/512MB/1GB *1
DDR2B2 256MB/512MB/1GB *1
Max is 2GB.
