2.3 INSTALLING SYSTEM MEMORY
A. Memory Modules
DDR2 _A1 DDR2 _B1 DDR2 _A2 DDR2 _B2
1. Unlock a DIMM slot by pressing the retaining clips outward. Align a
DIMM on the slot such that the notch on the DIMM matches the
break on the Slot.
2. Insert the DIMM vertically and firmly into the slot until the retaining
chip snap back in place and the DIMM is properly seated.
