Motherboard Manual
22
Over Clock Retry Count
This item allows you to set the overclock fail retry times.
FSB(Bsel) To NorthBridge Latch
This item allows you to select the FSB Frequency.
DRAM Fre que ncy
To get better system performance, sometimes downgrading the memory
frequency is necessary when CPU frequency is adjusted over the upper
limit.
DDR2 Enhanced Mode
This item allows you to control the DDR2 ram enhanced mode.
DRAM Timing Configuration
Enter this item for more advanced DRAM timing settings.
Clock Ge n Config urat io n
Enter this item for more advanced Clock Gen settings.
ALL Voltage Configuration
Enter this item for more advanced voltage settings.
Automatic Overclock System (A.O.S.)
For beginners in overclock field, BET had developed an easy, fast, and
powerful feature to increase the system performance, named A.O.S.
Based on many tests and experiments, A.O.S. provides 3 ideal overclock
configurations that are able to raise the system performance in a single step.
BIOS SETUP UTILI TY
Main Advan ced PCIPnP Boot Chipset O.N.E
vxx.xx (C)Copyri ght 19 85-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Over-Clockin g Navigato r setting
WARNING: Set ting wrong values in below sections
may cause sys tem to malfunction.
=========== Automa te Over Clock System ===========
============ Manual Ov erClock System ============
Over-Clockin g Navigato r [Normal]
Memory Test [Disabled]
Auto OverClo ck System [V6-Tech Engine]
Intel(R) SpeedStep (tm) tech [Enabled]
Ratio CMOS S etting [ x10.0]
CPU Frequenc y Setting [266]
Over Clock R etry Count [3]
FSB(Bsel) To NorthBrid ge Latch [Auto]
DRAM Frequen cy [Auto]
DDR2 Enhance d Mode [Auto]
> DRAM Timin g Configur ation
> Clock Gen Configur ation
> ALL Voltag e Configur ation
Exit
Options
Normal
Automate OverClock
Manual OverClock
Options
Normal
Manual OverClock
Automate OverClo ck
NOTE
Overclock is an optional process, but not a “must-do” process; it is not
recommended for inexperienced users. Therefore, we will not be responsible
for any hardware damage which may be caused by overclocking. We also
would no t
g
uarantee an
y
overclockin
g
p
erformance.
