1.3 MOTHERBOARD FEATURES
TP45D2- A7 TP43D2- A7
CPU
LGA 775
Intel Core2Duo / Core2Quad /
Pent iu m Dual-Core / C eleron Du al- Core /
Celeron 4xx processor
Supports Execute Disable B it / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
LGA 775
Intel Core2Duo / Core2Quad /
Pent iu m Dual-Core / C eleron Du al- Core /
Celeron 4xx processor
Supports Execute Disable B it / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
FSB Support 800 / 1066 / 1333 / 1600 MHz Support 800 / 1066 / 1333 / 1600 MHz
Chipset
Intel P45
Inte l ICH1 0
Intel P43
Inte l ICH1 0
Super I/O
ITE 8718F
Provides the most common ly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control in it iatives ,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian " function
ITE 8718F
Provides the most common ly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control in it iatives ,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian " function
Main
Memory
DIMM Slots x 4
Each DIMM supports 256MB / 512MB / 1GB /
2GB DDR2
Max Memory Capicity 8GB
Dual Channel Mode DDR2 memory module
Supports DDR2 1066 / 800 / 667
Registered D IMM and ECC DIMM is not
supported
DIMM Slots x 4
Each DIMM supports 256MB / 512MB / 1GB /
2GB DDR2
Max Memory Capicity 8GB
Dual Channel Mode DDR2 memory module
Supports DDR2 1066 / 800 / 667
Registered D IMM and ECC DIMM is not
supported
IDE
JMicro JMB368
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4
JMicro JMB368
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 specif icat ion co mp liant
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 specif icat ion co mp liant
LAN
Realtek RTL 8111C
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Realtek RTL 8111C
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC662
5.1 channels audio out
High Definition Audio
ALC662
5.1 channels audio out
High Definition Audio
