Viotech 3200+ BIOS Manual
26
DRAM Clock
This item allows you to set the Memory Clock.
Options: Auto (Default) / DDR3-800 / DDR3-1066
DRAM Timing
This item allows you to choos e to manually or automatically regulate the DRAM
Timing.
Options: Auto (Default) / Manual
CAS La tency (CL)
Options: 7T/8T (Default) / 3T/4T ~ NA/11T
Precharge to Active (Trp)
Optio ns: 9T/11T (Default) / 2T/4T ~ 8T/10T
Active to Precharge (Tras)
Optio ns: 20T/30T (Default) / 5T/15T ~ 19T/29T
Active to CM D (Trcd)
Optio ns: 9T/11T (Default) / 2T/4T ~ 8T/10T
REF to ACT/REF to REF (Trfc)
Optio ns: 73T /156T (Default) / 10T/30T ~ 72T/154T
ACT (0) to ACT (1) (Trrd)
Options: 9T/9T (Default) / 2T/2T ~ 8T/8T
Read to Precharge (Trtp)
Options: 5T/6T (Default) / 2T/3T ~ 4T/5T
Write to Read CMD (Twtr)
Options: 9T/9T (Default) / 2T/NA ~ 8T/8T
