Birch CD-108E - Setup Insertion Configuration; Configuring Output Character Insertion

59
End Configuration
Save Configuration
Setup Insertion
To setup the insertion of output characters:
1. Scan the label of the desired set.
2. Scan the label of the desired symboligy.
3. Go to the Decimal Value Tables in Appendix A, scan
label(s) that represents the desired position to be inserted.
4. Scan the "Complete" label of "Character Position to be
Inserted".
5. Go to the ASCII Tables in Appendix B or Function Key
Tables in Apendix C, scan label(s) that represents the
desired characters to be inserted.
6. Scan the "Complete" label of "Characters to be Inserted".
Repeat the steps 1 - 6 to set additional insertion.
Select Insertion Set Number
1st Set
2nd Set
3rd Set
4th Set
5th Set
6th Set
%500+
%502+
%503+
%504+
%505+
%501+
Setup Insertion
Operation
