Birch CD-108E - Method of Programming Parameters; Programming Flow and Loop Overview

7
Setup Flow Chart
Loop of Programming
The philosophy of programming parameters has been
shown on the flow chart. Basically user should
1. Scan Start of Configuration.
2. Scan all necessary labels for parameters that meet
applications.
3. Scan End of Configuration to end the programming.
4. To permanently save the settings you programmed, just
scan label for Save Parameters.
5. To go back to the Default Settings, just scan label for Set
All Defaults.
Start
Configuration
Set All
Defaults
Recall
Parameters
Interface Selection
Input Port Selection
Communication
Parameters
Bar Codes Parameters
MSR Parameters
Misc. Parameters
etc.
End
Configuration
Save
Parameters
Abort
Configuration
Method of Programming
