BIRD THRULINE 4027F series User Manual

Introduction
4
Figure 3 Power Sensor Outline Drawing 4028B Series only
Figure 4 Power Sensor Outline Drawing 4028C Series only
Frequency and Power Ranges
4020 Series
Model Frequency Range RF Power Range
4021 1.8 – 32 MHz 300 mW – 1 kW
4022 25 – 1000 MHz 300 mW – 1 kW
4024 1.5 – 32 MHz 3 W – 10 kW
4025 100 kHz – 2.5 MHz 3 W – 10 kW

BIRD THRULINE 4027F series Specifications

General

Brand	BIRD
Model	THRULINE 4027F series
Category	Measuring Instruments
Language	English
