birddog X1 - Technical Specifications

4
TECHNICAL SPECIFICATIONS
3
USER MANUAL
Feature X1 X1 Ultra
IMAGING
Image Sensor Sony 1/2.8” CMOS • FULL HD Sony 1/2.8” CMOS • ULTRA HD
Lens f=5.5mm - 110mm f=4.1mm - 49.2mm
Optical Zoom 20x 12x
Video Format 1080p @ 60/59.94/50/30/29.97/25fps
720p @ 60/50/30/25fps
2160p @ 30/29.97/25fps
1080p @ 30/29.97/25fps
720p @ 30/29.97/25fps
Horizontal angle of view 55.8º (W) – 3.2º (T) 70.28º (W) - 6.57º (T)
Vertical angle of view 32.2º (W) – 1.8º (T) 42.06º (W) - 3.76º (T)
Diagonal angle of view 61º (W) – 3.64º (T) 78.36º (W) - 7.5º (T)
Aperture F1.6 ~ 3.5 F1.8 ~ 2.68
Focus Auto, Manual
Exposure Auto, Shutter Priority, Iris Priority, Manual
Backlight Compensation YES
Digital Noise Reduction 2D and 3D Noise Reduction
SNR >50dB
2.07 MP 8.29 MP
MECHANICAL
Pan/Tilt Rotation ±175º, -90º ~ +90º
Pan Control Speed 0.1 -80º/sec
Tilt Control Speed 0.1 -60º/sec
Preset Number 255 presets
I/O INTERFACE
Video Output Interfaces HDMI, USB-C UVC 1.1, Network
Video Compression Format H.264, H.265
Network Interfaces 100M adaptive Ethernet port; POE IEEE802.3af, Wi-Fi IEEE 802.11ac
Encoder Network Protocol
NDI|HX2, NDI|HX3, RTSP, RTMP
Control Interface 10M/100M Ethernet, Wi-Fi IEEE 802.11ac, RS232 (input & output), RS485, TYPE-C(UVC1.1)
Control Protocol VISCA Baud Rate: 38400/9600/4800/2400, VISCA-IP, NDI
GENERAL
Input Voltage DC 12V, PoE IEEE802.3af
Input Current 2.0A (Max.)
Power Consumption 13W (Max.)
Working Temperature
Working Humidity 20% ~ 80%
Dimension (W*H*D) 171.6*192.6*171.6mm / 260*217*197mm (before / after packing)
Net and Gross Weight 1.35kg/2.05kg (Net/Gross weight) 1.43kg/2.096kg (Net/Gross weight)
-10ºC ~ +40ºC
Effective Pixels
HDMI Decoder Network Protocols
NDI|HX2, NDI|HX3
