CAMERA MENU
5
Press【MENU】on the remote control to enter
main menu of the ptz camera.
5.1 Level 1 Menu - Main Menu
Language: Support Chinese/English.
Click the Home button on the Remote to enter
level 2 sub-menu.
Click the Menu button on the Remote to exit
menu.
5.2 Level 2, Menu - Exposure
Mode: Auto/Manual
Backlight Comp. : You can turn On/Off the
backlight. When the background of the subject is
too bright, or when the subject is too dark, back-
light comp. will make the subject appear clearer.
Exp. Comp. (exposure compensation): When
mode is set to Auto, set this item to ON to enable
exp. comp. When you set it to ON, you can
select the exp. comp. level from 0 to 15.
Flicker: Support 50Hz/60Hz.
When changing the exposure mode to Manual,
the sub-menu is the following
Main Menu
Exposure
Color
Information
Restore Default
Language
[Home]
[Menu]
English
Enter
Back
Exposure
Mode
Backlight
ExpComp
Flicker
[Return]
Auto
On/Off
0-15
50/60Hz
Exposure
Mode
Iris
Shutter
Gain
Flicker
[Return]
Manual
F1.6
1/100000~1/25
50
50Hz/60Hz
Iris: F No. Setting, the value should be
F1.6/F2.0/F2.4/F2.8/F3.4/F4.0/
F4.8/F5.6/F6.8/F8.0/F9.6
Shutter: Shutter value setting, the value is
between 1/100000 and 1 Gain, exposure gain
setting, optional item is 0 to 99
5.3 Level 2 Menu-Color
Color
Brightness
Contrast
Hue
Saturation
Sharpness
WB Mode
Rtuning
Btuning
[Return]
50
50
50
50
50
Auto
50
50
Brightness: Set image brightness Dynamically.
Default 50, optional item 0-99
Contrast: Set image contrast Dynamically.
Default 50, optional item 0-99 Hue: Set the
relateive brightness of the image. Default 50,
optional item 0-99
Saturation: Set image color effect. Default 50,
optional item 0-99 Sharpness: Set sharpness
level. Default 50, optional item 0-99 WB
mode: Auto/Manual/VAR
When the WB mode is Auto, the R-tuning and
B-tuining value can be tuning, the range is 0
to 99;
