P/N : 550-ENG-OPM-EUR-R01
1.5 Description of System components
Figure1-3: System components
Name Description
①
Head
Equipped with infrared radiating light source and can be rotated
up to 90° to left and right each and totally 180°.
②
Column
Supporting head part and equipped with electronic circuits to
he electronic circuits are composed with
power supply part, display and user interface.
The IV pole and plate for auxiliary equipment attached on the
side of column when the option has been selected.
③
Stand
Supporting the whole BT-550 system. Basic stand has fixed
height. Height adjustable stand is available as option.
It has equipped with caster to move the BT-550 easily and can be
fitted with drawer and bed tilting mechanism when options are
selected.
④
Bed
Equipped with mattress and protective barriers to prevent the
patient from falling off the mattress. X-ray cassette tray is located
under the bed for X-ray procedure. Weighing scale plate can be
placed beneath the mattress as option.
Protective barriers can be opened or removed from the bed for
easy access to infant patient.
