Bistos BT-550 User Manual

BT-550 Operation manual
53
P/N : 550-ENG-OPM-EUR-R01
Bistos Co., Ltd.
2018.03
6.3 Electromagnetic immunity
The BT-550 is intended for use in the electromagnetic environment specified below.
The customer or the user of the BT-550 should assure that it is used in such an
environment.
Immunity test
IEC 60601
Test level
Compliance level
Electromagnetic
environment -guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV Contact
±8 kV air
±6 kV Contact
±8 kV air
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be
at least 30 %.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply lines
±1 kV for
input/output lines
±2 kV for power
supply lines
±1 kV for
input/output lines
Mains power quality should
be that of a typical
commercial or hospital
environment.
Surge
IEC 61000-4-5
±1 kV line(s) to
line(s)
±2 kV line(s) to
earth
±1 kV line(s) to
line(s)
±2 kV line(s) to
earth
Mains power quality should
be that of a typical
commercial or hospital
environment.
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
< 5 % Uт
(> 95 % dip in Uт)
for 0.5cycle
40 % Uт
(60 % dip in Uт )
for 5 cycle
70 % Uт
(30 % dip in Uт)
for 25 cycle
<5 % Uт
(> 95 % dip in Uт )
for 5 s
< 5 % Uт
(> 95 % dip in Uт)
for 0.5cycle
40 % Uт
(60 % dip in Uт )
for 5 cycle
70 % Uт
(30 % dip in Uт)
for 25 cycle
<5 % Uт
(> 95 % dip in Uт )
for 5 s
Mains power quality should
be that of a typical
commercial or hospital
environment. If the user of
the BT-550 image
intensifier requires
continued operation during
power mains interruptions,
it is recommended that the
BT-550 image intensifier be
powered from an
uninterruptible power
supply.
Power frequency
(50 Hz and 60 Hz)
magnetic field
IEC 61000-4-8
3 A/m
3 A/m
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
NOTE Uт is the a.c. mains voltage prior to application of the test level.
