BITMAIN ANTMINER S19 Pro User Manual

- 13 -
S19 Pro Server Installation Guide
4. Monitoring Your Server
4. Monitoring Your server
To check the operating status of your server:
1. Click dashboard marked below to check the server status.
Note: The S19 Pro server is with fixed frequency 675 MHz. Firmware will stop running when the Temp
(Outlet) reaches to 95℃，there will be an error message “over max temp, pcb temp (real-time temp)”
shown on the bottom of kernel log page. Meanwhile, the server temperature on the dashboard interface
turns to abnormal and shows “Temp is too high”.
2. Monitor your server according to the descriptions in the following table:
Option
Description
Number of chips
Number of chips detected in the chain.
Frequency
ASIC frequency setting.
Real Hashrate
Real-time Hashrate of each hash board (GH/s).
Inlet Temp
Temperature of the inlet (°C).
Outlet Temp
Temperature of the outlet (°C).
Chip state
One of the following statuses will appear:
● The Green Icon - indicates normal
● The Red Icon- indicates abnormal

BITMAIN ANTMINER S19 Pro Specifications

General

Hash Rate	110 TH/s
Power Consumption	3250W
Power Efficiency	29.5 J/TH
Noise Level	75 dB
Dimensions	370 x 195.5 x 290 mm
Weight	13.2 kg
Operating Temperature	0 - 40 °C
Network Connection	Ethernet
Chip Type	BM1397
Algorithm	SHA-256
Manufacturer	Bitmain
Model	Antminer S19 Pro
Category	Server
Release Year	2020
Supported Coins	Bitcoin, Bitcoin Cash
Voltage	220-240V
Cooling	Dual Fans
