Bitronics M350 User Manual

ML0038 September 27, 2017 - 64 - Copyright 2017 Bitronics, LLC
Available Measurements
Demand Amps A, B, C Factor
y
Version Software
Factor
y
Version Hardware Health
Factor
y
Version Software Heartbeat
Health Meter T
y
pe
Heartbeat Protocol Version
Meter T
y
pe PT Scale Facto
r
Protocol Version PT Scale Factor Diviso
r
Volts AN, BN, CN, AB, BC, C
A
6.7 Calibration
Routine re-calibration is not recommended or required. A field calibration check every
few years is a good assurance of proper operation.
6.8 Instantaneous Measurement Principles
The M350 measures all signals at an effective rate of 64 samples/cycle,
accommodating fundamental signal frequencies from 45 to 65Hz depending on model.
Samples of all bus signals are taken using a 16-Bit A/D converter, effectively creating
64 "snapshots" of the system voltage or current per cycle.

Bitronics M350 Specifications

General

Brand	Bitronics
Model	M350
Category	Measuring Instruments
Language	English
