BIXOLON SPP-R410 - Wireless LAN Configuration and Self-Test; WLAN Interface Settings; WLAN Self-Test Output Sample

Rev. 1.00
- 23 -
SPP-R410
• Self-Test Sample (For Wireless LAN)
Firmware version :
V01.00 STOBa 010117
Butter Capacity : 256K Bytes
USB 2.0 Interface
Serial Interface
- Baud rate : 115200 bps
- Data bits : 8 bits
- Parity : None
- Stop bit : 1 bit
- Handshaking : DTR/DSR
Print Density : 100%
Default Codepage : PC437
Print Speed : Max. 90mm/s
Double byte character mode: Off
Font : 12 x 24
Paper out Bell : Off
Low Battery Buzzer : On
Black mark : Off
Power off time : 15 Min
Idle mode time : 10 Sec
MSR data including sentinel
Character mode : None
MSR read mode : Auto TRACK1/2/3
BATT NTC : OK
Memory switch setup status
Memory S/W1 Memory S/W2
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
ON █ █ ON
OFF █ █ █ █ █ █ OFF █ █ █ █ █ █ █ █
Memory S/W3 Memory S/W4
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
ON █ █ █ █ ON
OFF █ █ █ █ OFF █ █ █ █ █ █ █ █
Memory S/W5 Memory S/W6
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
ON █ █ █ █ ON █ █
OFF █ █ █ █ OFF█ █ █ █ █ █
Memory S/W7 Memory S/W8
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
ON █ █ █ ON
OFF █ █ █ █ █ OFF █ █ █ █ █ █ █ █
RF Interface
Not available Bluetooth
WLAN F/W version : 02.00(3930)
System Name : SPP-R410
Network Mode : Soft AP
Frequency : (Priority)2.4GHz / 5GHz
Authentication : Open
Encryption : None
ESSID : PRINTER_B01A93
DHCP : Enable
IP Address : 192.168.1.1
Subnet Mask : 255.255.255.0
Gateway : 192.168.1.2
Port : 9100
Inactivity Time: 10
WLAN MAC address :
If you want to continue
SELF-TEST printing,
Please press FEED button.
ASCII
! ” # $ % & ’ ( ) * + , - . / 0 1 2 3 4 5 6 7 8 9 : ; < = > ? @
”#$%&’()*+,- . / 0 1 2 3 4 5 6 7 8 9 : ; < = > ? @ A
# $ % & ’ ( ) * + , - . / 0 1 2 3 4 5 6 7 8 9 : ; < = > ? @ A B
$ % & ’ ( ) * + , - . / 0 1 2 3 4 5 6 7 8 9: ; <= > ? @ A B C
% & ’ ( ) * + , - . / 0 1 23 45 6 78 9: ; < => ? @ A B C D
& ’ ( ) * + , - . / 0 1 2 3 4 5 6 7 8 9 : ; < = > ? @ A B C D E
’ ( ) * + , - . / 0 1 2 34 5 6 7 8 9 : ; < = > ? @ A B C D E F
()* +, -. /0 123 4 56 7 89 : ; < = >? @ABCD E FG
)*+,-./0123456789:;<=>?@ABCDEFGH
*+,-./ 0 1 23456789:;<=>?@AB C DE FG HI
+,-./0123456789: ;<=>?@ABCDE FGHIJ
,-./0123456789: ;<=>?@ABCDE FGHIJK
-./0123456789:;<=>?@ABCDEFG HIJKL
./0123456789:;<=>?@ABCDEFGHIJKLM
/0123456789:;<=>?@ABCDEFGHIJKLMN
0123456789:;<=>?@ABCDEFGHIJKLMNO
123456789:;<=>?@ABCDEFGHIJKLMNOP
23456789:;<=>?@ABCDEFGHIJKLMNOPQ
3456789:;<=>?@ABCDEFGHIJKLMNOPQR
456789:;<=>?@ABCDEFGHIJKLMNOPQRS
56789:;<=>?@ABCDEFGHIJKLMNOPQRST
6789:;<=>?@ABCDEFGHIJKLMNOPQRSTU
789:;<=>?@ABCDEFGHIJKLMNOPQRSTUV
89:;<=>?@ABCDEFGHIJKLMNOPQRSTUVW
9:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWX
PC437
Ç ü é â ä à å çê ë è ïîìÄ Å É æ Æ ô ö ò û ù ÿÖ Ü ¢ £ ¥ Pt ƒ
ü é â ä à å çê ë è ïîìÄ Å É æ Æ ô ö ò û ù ÿÖ Ü ¢ £ ¥ Pt ƒá
é â ä à å çê ë è ïîìÄ Å É æ Æ ô ö ò û ù ÿÖ Ü ¢ £ ¥ Pt ƒáí
â ä à å çê ë è ïîìÄ Å É æ Æ ô ö ò û ù ÿÖ Ü ¢ £ ¥ Pt ƒáíó
ä à å ç ê ë è ïîìÄ Å É æ Æ ô ö ò û ù ÿÖ Ü ¢ £ ¥ Pt ƒáíóú
à å çê ë è ïîìÄ Å É æ Æ ô ö ò û ù ÿÖ Ü ¢ £ ¥ Pt ƒáíóúñ
å çê ë è ïîìÄ Å É æ Æ ô ö ò û ù ÿÖ Ü ¢ £ ¥ Pt ƒáí ó úñÑ
çê ë è ïîìÄ Å É æ Æ ô ö ò û ù ÿÖ Ü ¢ £ ¥ Pt ƒáíóúñѪ
ê ë è ïîìÄ Å É æ Æ ô ö ò û ù ÿÖ Ü ¢ £ ¥ Pt ƒáíóúñѪº
ëèïîìÄ Å É æ Æ ô ö ò û ù ÿÖ Ü ¢ £ ¥ Pt ƒáíóúñѪ º ¿
è ïîìÄ Å É æ Æ ô ö ò û ù ÿÖ Ü ¢ £ ¥ Pt ƒáíóú ñ Ѫº¿┌
ïîìÄ Å É æ Æ ô ö òû ùÿÖ Ü ¢ £¥ Pt ƒáíó úñ Ѫ º¿┌ ┐
îìÄ Å É æ Æ ô ö òûùÿÖ Ü ¢£¥ Pt ƒáíóúñѪº¿┌ ┐½
ìÄ Å É æ Æ ôöòûùÿÖ Ü ¢£¥ Pt ƒáíóúñѪº¿┌ ┐½¼
Ä Å É æ Æ ôöòûùÿÖ Ü ¢£¥ Pt ƒáíóúñѪº¿┌ ┐½¼¡
Å É æ Æ ôöòûùÿÖ Ü ¢£¥ Pt ƒáíóúñѪº¿┌ ┐½¼¡«
É æ Æ ôöòûùÿÖ Ü ¢£¥ Pt ƒáíóúñѪº¿┌ ┐½¼¡«»
æ Æ ôöòûùÿÖ Ü ¢£¥ Pt ƒáíóúñѪº¿┌ ┐½¼¡«»▓
Æ ôöòûùÿÖ Ü ¢£¥ Pt ƒáíóúñѪº¿┌ ┐½¼¡«»▓▒
ôöòûùÿÖ Ü ¢£ ¥ Pt ƒáíóúñѪº¿┌ ┐½¼¡«»▓▒░
öòûùÿÖ Ü ¢£¥ Pt ƒáíóúñѪº¿┌ ┐½¼¡«»▓▒░┃
òûùÿÖ Ü ¢£¥ Pt ƒáíóúñѪº¿┌ ┐½¼¡«»▓▒░┃┤
ûùÿÖ Ü ¢£¥ Pt ƒáíóúñѪº¿┌ ┐½¼¡«»▓▒░┃┤╡
ùÿÖ Ü ¢£¥ Pt ƒáíóúñÑ ªº¿ ┌ ┐½¼¡«»▓▒░┃┤╡╢
ÿÖ Ü ¢£¥ Pt ƒáíóúñѪº¿┌┐½¼¡«»▓▒░┃┤╡╢╖
*** Completed ***
