Page #16 background imageLoading...
Page #16 background image
Rev. 2.00
- 16 -
SRP-275 Ver.2
3-1-2 DIP Switch setting for Star(SP500) mode
• DIP Switch 1
Switch Function ON OFF Default
1-1
1-2
Emulation Selection (*1) Refer to the following table OFF
1-3 Auto cutter Enable Disable OFF
1-4 Black/Red Printing Enable Disable OFF
1-5
1-6
1-7
1-8
Reserved OFF
• DIP Switch 2 (RS232C serial interface model)
Switch Function ON OFF Default
2-1
2-2
Reserved OFF
2-3 Hand shaking XON/XOFF DTR/DSR OFF
2-4 Word length 7 bits 8 bits OFF
2-5 Parity check Enable Disable OFF
2-6 Parity selection EVEN ODD OFF
2-7 OFF
2-8
Baud rate selection (*2) Refer to the following table
OFF
NOTES
(*1) Emulation Selection (DSW 1-1 and 1-2)
Emulation 1-1 1-2
BXL/POS OFF OFF
BXL/POS-KP ON ON
STAR OFF ON
CITIZEN ON OFF
- BXL/POS-KP(Kitchen Printer mode) : A alarm is generated by printer after auto cutting and in paper end error.
(*2) Baud rate selection (Transmission speed)
Transmission 2-7 2-8
2400 baud ON ON
4800 baud OFF ON
9600 baud OFF OFF
19200 baud ON OFF
NOTICE
Change in DIP Switch settings are recognized only when the printer power is turned on or when the
printer is reset by using the interface. If the DIP Switch setting is changed after the printer power is
turned on, the change does not take effect until the printer is turned on again or is reset.
