SRP-350
2-2-3 Setting the DIP switch (IEEE1284 Parallel, USB Interface)
• DIP Switch 1
SW Function ON OFF Default
1 Auto Line Feed Always enabled Always disabled OFF
2 Reserved - - OFF
3 Reserved - - OFF
4 Reserved - - OFF
5 Reserved - - OFF
6 Reserved - - OFF
7 Reserved - - OFF
8 Reserved - - OFF
• DIP Switch 2
SW Function ON OFF Default
1 Code Page Selection Refer to the Following Table 3 OFF
2 Internal bell control Internal bell disable Internal bell enable OFF
3 Auto Cutter Selection Disable Enable OFF
4 Code Page Selection Refer to the Following Table 3 OFF
5 OFF
6
Select Print Density Refer to the Following Table 2
OFF
7 Near End Sensor Status Disable Enable OFF
8 Code Page Selection Refer to the Following Table 3 OFF
• Table 1 – Baud rate (bps) Selection
Transmission speed SW – 7 SW – 8
9600 baud ON OFF
19200 baud OFF OFF
38400 baud ON ON
57600 baud OFF ON
• Table 2 – Print Density Selection
Print Density SW - 5 SW – 6
1 ( Light ) ON ON
2 OFF OFF
3 ON OFF
4 ( Dark ) OFF ON
• Table 3 – Code Page Selection
Code Page SW – 1 SW – 4 SW - 8
PC 437 OFF OFF OFF
PC 737 OFF OFF ON
PC 852 OFF ON OFF
PC 857 OFF ON ON
PC 864 ON OFF OFF
PC 866 ON OFF ON
WPC 1251 ON ON OFF
WPC 1254 ON ON ON
