BIXOLON SRP-350plusV Bluetooth Connection Manual

Bluetooth Connection Manual
Ver.1.00
- 5 -
3. Bluetooth Information Printing
After the printer has finished booting, open the printer cover and press and hold the
FEED Button. This will cause the interface setting confirmation mode.
Then add the paper, close the cover, and check that the following message is printed.
Errors LED is toggled/blinked until Bluetooth is booted.
The number of Bluetooth setting information may be different for each
interface type of the product.
3-1 Bluetooth Information Print
• If the above message is printed, select Mode 1, and you will see the following
Bluetooth data. (To select Mode 1, press the Feed button once quickly/ once long.)
Checking Interface Setting
0: Exit
1: LAN Information Print
2: LAN Factory Reset and Reboot Printer
3: B/T Information Print
4: B/T Factory Reset and Reboot Printer
5 or more: None
Select Modes by Feed button control
as below.
Step 1. Short-press as many times as
The mode number to choose.
Step 2. Long-press over 1 second.
*e.g. To choose Mode 2, press Feed
Button 3 times(short-short-long)

BIXOLON SRP-350plusV Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Black
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 / 60 Hz
Maximum roll diameter	79.5 mm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Mobile operating systems supported	Android, iOS
Windows operating systems supported	Yes
Serial interface	-
Optional connectivity	Bluetooth, Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Internal memory	- MB
Autocutter durability	2 million cuts

Weight and Dimensions

Depth	200 mm
Width	145 mm
Height	146 mm
