BIXOLON SRP-E300 Connection Manual

Ver. 1.00
- 13 -
SRP-E300/302
5. Factory Reset
This function changes the LAN settings of the printer to the initial factory settings.
1) Procedure
After the printer has finished booting, open the printer cover and press and hold the FEED
button for 5 seconds. This will cause the interface setting confirmation mode. Then add the
paper, close the cover, and check that the following message is printed.
If the above message is printed, select Mode 2, and you will see the following LAN
information. (To select Mode 2, press the Feed button twice quickly / once long.)
Checking Interface Setting
0: Exit
1: LAN Information Print
2: LAN Factory Reset and Reboot Printer
3 or more: None
Select Modes by Feed button control
as below.
Step 1. Short-press as many times as
The mode number to choose.
Step 2. Long-press over 1 second.
*e.g. To choose Mode 2, press Feed
Button 3 times(short-short-long)
Feed Button
Cover Open Lever

BIXOLON SRP-E300 Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum roll diameter	83 mm
Supported paper width	80 mm
Maximum printing width	72 mm
Printing media thickness	0.062 - 0.075 µm
USB port	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Product color	Black
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Internal memory	- MB
Built-in barcodes	1D, 2D, Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, PDF417, QR Code, UPC-A, UPC-E
Autocutter durability	1.5 million cuts
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	182.4 mm
Width	132 mm
Height	128.5 mm
