BIXOLON SRP-E300 Connection Manual

Ver. 1.00
- 6 -
SRP-E300/302
4. Ethernet Test by using Windows Test Page
You can use the Windows printer driver as shown below when there is no test program.
Operating systems that allow you to use the Windows printer driver are Windows, XP,
Server 2003, VISTA, 2008 Server, 7, 8, 10.
[Note]
-The Windows driver is included in the CD, and you can download the latest version
from our home page.
(www.bixolon.com)
1) Double-click the Windows Driver installation file.
2) Click Install

BIXOLON SRP-E300 Specifications

General

Type	POS printer
Color	No
Print technology	Direct thermal
Maximum roll diameter	83 mm
Supported paper width	80 mm
Maximum printing width	72 mm
Printing media thickness	0.062 - 0.075 µm
USB port	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Product color	Black
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Internal memory	- MB
Built-in barcodes	1D, 2D, Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, PDF417, QR Code, UPC-A, UPC-E
Autocutter durability	1.5 million cuts
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	182.4 mm
Width	132 mm
Height	128.5 mm
