BIXOLON SRP-F310II User Manual

SRP-F310/F312/F313II
Ver. 2.00
- 13 -
2-2 Interface Part Names
• Connect the printer to the host computer using the right interface cable that
complies with the specifications of the interface.
2-2-1 USB (Built-in)
Pin No.
Signal Name
Assignment (Color)
Function
Shell
Shield
Drain Wire
Frame Ground
1
VBUS
Red
Host Power
2
D-
White
Data Line (D-)
3
D+
Green
Data Line (D+)
4
GND
Black
Signal Ground
Connect or disconnect the communication cable while the printer
power is off. If power is on, your data may be lost.
Ethernet port
USB Port
