BIXOLON SRP-F310II User Manual

SRP-F310/F312/F313II
Ver. 2.00
- 22 -
3-2 Turn on the Power
1) After turning the printer off, connect the power cord jack to the printer’s power
port.
2) Plug it into the power outlet on the wall.
2) Press the “ON” switch to turn on the printer.
- Check the power supply’s label to check its electronic specs.
- Only use a power supply provided by BIXOLON. BIXOLON shall
bear no responsibility for damage caused by using a third-party
power supply.
- When removing the power supply, make sure you have a firm
grasp of the plug terminal of the power jack and the printer
and pull horizontally.
- When connecting or disconnecting power, make sure to remove
the power supply from the power outlet before removing.
- Pay attention to the direction in which you insert the
power cord.
- Do not connect a voltage out of the specifications of the power
supply. It can cause damage to the product or a fire.

BIXOLON SRP-F310II Specifications

General

Print Method	Direct Thermal
Print Width	Up to 72 mm
Paper Thickness	0.06 ~ 0.08 mm
Weight	1.5 kg
Paper Loading	Easy Paper Loading
NV Image	Yes
Resolution	203 dpi
Interface	USB, Serial, Ethernet, Bluetooth
Paper Width	80 mm
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0 ~ 45 °C
Storage Temperature	-20 ~ 60 °C
Humidity	10% to 80% RH (non-condensing)
Emulation	ESC/POS
Receive Buffer	4 KB
