To Next Page

To Previous Page

Recall No.

Output Voltage

Output Current

5 V

Maximum

13.8 V

Maximum

Model 1685B: 55 V

Model 1687B: 25 V

Model 1688B: 15 V

Maximum

Table 3 - Default Presets

4.2.3 Analog Remote Control Mode

Select this mode to control the output voltage and current via remote control

connector. Please refer to Section 5.1 for more details.

4.2.4 Set Mode

First, enter Set Mode by pushing Mode Selection Switch to “Set” position.

To define the preset output P1/P2/P3

1. Select the Recall Switch to the position you want to set: P1, P2, or P3.

2. Adjust the front panel voltage control knob to set your desired voltage

value.

3. Adjust the front panel current control knob to set your desired current limit

value.

4. Repeat the procedure for remaining presets P1, P2, or P3 if desired.

5. Move Mode Selection Switch from “Set” to “Preset” position to confirm your

settings.

BK Precision 1688B User Manual
