12
2.4 Front Panel Menu Overview
The menu is organized in a top-down tree structure with three levels (menus, commands and
parameters) as shown in Figure 2-3. You can use down ( ) or up ( ) to move menu tree from
one level to another. Each of the three levels has several horizontal choices which you can view by using
left ( ) or right ( ).
Figure 2-3 Menu Tree
! To turn on the menu, press → (Menu).
! To turn off the menu, press → (Menu), or press any of the function or math keys on
the front panel.
! To confirm a change on the “parameter” level, press (ENTER).
! To cancel a change on the “parameter” level, press (Menu).
Note: If you press on the “menu” level, this is the top level of the menu and you
cannot go any higher; similarly if you press on the “parameter” level, this is the bottom
level of the menu and you cannot go any lower.
