19
6. Press + to turn on the secondary display, Use or key to choose the
function for secondary display.
7. Take readings from the display.
Input Resistance = 10 MΩ
CAUTION: Maximum Input = 1010 V peak
Input Impedance = 1.1 MΩ and 100 pF
CAUTION: Maximum Input = 750 V RMS or 1000 V peak, 3x10
7
V-Hz
Figure 3-1 DC and AC Voltage Measurement Connections
