Operation Modes 57
Step 8. Use the numeric keypad to set the current END value. Press the
to conrm the current
value that will terminate the test.
Step 9. Use the numeric keypad to set the OCP VOLT value. Press the
to conrm the voltage
stop condition.
This threshold serves as a benchmark for assessing Over Current Protection
(OCP) conditions. Should an overcurrent situation arise with the input voltage
surpassing this threshold, the test will progress incrementally from "Start Current"
to "End Current." Throughout this progression, the input current, representing
the overcurrent, will be scrutinized. If the current falls within the limits dened by
"Max Trip Current" and "Min Trip Current," the system will register a "Pass" at the
conclusion of the test. Conversely, if the current exceeds these boundaries, the
system will register a "Fault."
Step 10. Use the numeric keypad to set the MAX TRIP value. Press the to conrm the acceptable
upper current limit .
Step 11. Use the numeric keypad to set the MIN TRIP value. Press the
to conrm the acceptable
lower current limit .
Step 12. Use the numeric keypad to set the SAVE OCP FILE location. Press the to conrm the
memory location where the congured le will be stored.
• Upon pressing
the instrument will automatically exit the OCP Test Conguration
menu.
