System Menu 66
7.6 MEMORY
The instrument has the capability to store up to 100 settings in its non-volatile memory. This memory is
organized into 10 storage groups (group 0 to 9), with each group having 10 memory locations (0 to 9) for
storing settings. These locations are referenced by numbers 1 to 100. When saving a setting, numbers
1 to 100 are selected. However, during the recall process, the user must rst choose the group and then
use the numeric keypad buttons 1 through 9 and 0, corresponding to the 10 locations within the selected
storage group.
In recalling settings, each numeric keypad number corresponds to a memory location based on the
chosen storage group. For instance, for storage group 0, recalling memory location 1 is done by pressing
, location 2 by pressing , and so forth. Memory location 10 is recalled by pressing . Similarly, for
storage group 1, recalling memory location 11 is achieved by pressing , location 12 by pressing ,
and so on.
Example If settings are saved to memory location 60 and the user wishes to recall them, they
would set the storage group to 5 from the MEMORY GROUP submenu, then press the
+ buttons to enter the recall menu, and select address 0 by pressing the
button.
Storage Group Memory locations
0 1 – 10
1 11 – 20
2 21 – 30
3 31 – 40
4 41 – 50
5 51 – 60
6 61 – 70
7 71 – 80
8 81 – 90
9 91 - 100
Table 7.1 Memory Locations
