30
1. Press [CW] button press to set related +[parameters]
RANGE=150.00W
CV
2. Set the power range press to conrm.
RANGE =1.00W
3. Set the upper limit of voltage press to conrm.
HIGH=120.00V
4. Set the lower limit of voltage press to conrm.
LOW=0.000V
5. Finish the setup
10.0000V 0.000A
0.00W CW=1.00W
CR Mode
1. Press [CR] button, press [ +[CV] (Setup) to set related paramters.
RANGE=7500.0Ω
2. Set the resistance range press to conrm.
RANGE=2Ω
3. set the upper limit of voltage press to conrm.
HIGH=120.0V
4. Set the lower limit of voltage press to conrm.
LOW=0.000V
5. Finish the setup.
10.0000V 0.000A
0.00W CR=2.000Ω
Go into Autotest Mode
Operation Display on Front Pannel
1. Press + (system) to enter the system menu.
0.0000V 0.000A
POWER-ON BUZZER
2. Press right key, select RUNMODE and conrm with button.
0.0000V 0.000A RUN <NORMAL>
3. Press direction key to select OCP_TESTPress Enter to conrm.
0.0000V 0.000A RUN <PROG_TEST>
4. Press [Esc] button to leave the menu.
0.0000V 0.000A
P01
