29
1. Press [[Shift)+[CC] button and then [CV] (Setup) to enter the setting interface.
RANGE=30.000A
CC
2. Set the current range press to conrm.
RANGE =1.2A CC
3. set the upper limit of voltage, press to conrm.
HIGH=4.6V
CC
4. Set the lower limit of voltage, press to conrm.
LOW=4.4V
CC
5. Set the rise speed of current, press to conrm.
UP=1A/uS
CC
6. Set the fall speed of current, press to conrm.
DOWN=1A/uS
CC
7. Finish the setup
10.0000V 0.000A
0.00W CC=0.000A
CV Mode, 3V, Current Range 2A 3A
1. Press [CV] button press to set related +[parameters]
RANGE=120.00V
2. Set the voltage range press to conrm.
RANGE=3.00V
3. set the upper limit of current press to conrm.
HIGH=3A
4. Set the lower limit of current press to conrm.
LOW=2A
5. Finish the setup
10.0000V 0.000A
0.00W CV=10V
The CW and CR is set as the same way:
CW Mode
Steps Operation VFD Display
