Chapter 2: Overview
2.3 What's Included
Your package should include the following items. If anything is missing or damaged,
contact Black Box Technical Support at 877-877-2269 or info@blackbox.com.
• (1) Video Extender —4K HDMI, VGA, RS-232, Wallplate Transmitter with Audio (AVS-
HDB-WPTX)
• (4) Screws (for AVS-HDB-WPTX)
• (3) Pluggable Terminal Blocks ([1] 2-pin block, [1] 3-pin block, and [1] 4-pin block)
• (1) Faceplate
• (4) Screws (for the faceplate)
• This printed user manual
2.4 Hardware Description
2.4.1 Front Panel
1
2
3
4
5
6
7 8
9
Figure 2-1. Front panel.
