• Supports Windows
®
and Mac host systems.
• Compatible with most of the popular screen resolutions, such as XGA, SXGA,
UXGA, WSXGA, up to Full HD, WUXGA, WQXGA.
2.3 What’s Included
• (1) 2- or 4-port KVM switch
• (1) external power supply with U.S. power cord
• This user’s manual
• (4) rubber feet
2.4 Hardware Description
2.4.1 KV9702A Front and Back Panels
Figures 2-1 and 2-2 illustrate the front and back panels of the KV9702A. Table 2-1
describes its components.
1 2 3
Figure 2-1. KV9702A front panel.
4 5 6 7 9 10 11 12 13 14 15
8 16 17 18
Figure 2-2. KV9702A back panel.
