Page 7
Chapter 1: Specifications
Network Specifications
Character Count 0 to 65535
Connection Modes Server, Client
Memory Serial: 8 KB per port;
Network memory: 4 KB
Firmware Upgrade Via serial, Ethernet, or auto Web search
IP Port Addresses 5300: heartbeat and configuration setting in TCP mode;
8888: LES431A update
Network
Communications
LAN: 10-/100-Mbps auto-detecting 10BASE-T and 100BASE-TX
Network Physical
Layer Standards
Ethernet: IEEE 802.3 autodetecting and auto MDI/MDI-X 10BASE-T and 100BASE-TX
Protocols
Supported
TCP, IPv4, UDP, ARP, HTTP 1.0, ICMP/PING, DHCP/BOOTP;
IP mode: Static, DHCP, or Auto IP;
TCP: User-definable
Search Serial direct COM and Ethernet autosearch or specific IP
Timeouts Character: 0 to 65535 ms. default set at 10 ms;
Modbus Message: 0 to 65535 ms, default set at 1000 ms;
Serial: 0 to 65535 sec.
