Chapter 1: Specifications
1. Specifications
General Specifications
Approvals
FCC Part 15, Class A, CE, NEMA TS2, UL
®
Class 1, Division 2, Groups A, B, C, and D
Compatible
Operating Systems
Windows
®
XP (32/64 bit), 2003 Server (32/64 bit), Windows Vista
®
(32/64 bit),
2008 Server (32/64 bit), Windows 7 (32/64 bit)
Configuration
Options
Via serial port using Modbus Hardened Serial Server Software, via network using Modbus Hardened Serial
Server Software with an Ethernet connection or a standard Web browser such as Internet Explorer
®
7, 8, or 9,
or Firefox
®
3 or 4
Enclosure Rating: IP30;
Mounting: DIN rail mount (35 mm)
User Controls (1) Reset button
Connectors (1) DB9 M, (1) 5-pin terminal block, (1) RJ-45, (1) 2-position pluggable terminal block for power
Indicators (3) LEDs: (1) Ready, (1) Serial, (1) Ethernet Link
Temperature
Tolerance
Operating: -40 to +176° F (-40 to +80° C);
Storage: -40 to +185° F (-40 to +85° C);
Maximum Ambient Surrounding Air Temperature: 176° F (80° C)
Operating
Humidity
10 to 95%, noncondensing
Power Voltage requirements: 10 to 48 VDC (58 VDC max.) extermal power supply;
Consumption: 4.0 watts maximum;
Terminal blocks: Wire size: 28 to 16 AWG,
Wire Type: Copper wire only,
Tightening Torque: 5 kg-cm,
Wire Temperature Rating: 105° C minimum, sized for 60° C ampacity
NOTE: One conductor per terminal.
Dimensions 1.2"H x 3.3"W x 4.7"D (4.6 x 12.2 x 17.1 cm)
Serial Interface Specifications
Baud Rates 75, 150, 300, 600, 1200, 2400, 4800, 7200, 9600, 14400, 19200, 28800, 38400, 57600, 115200, 230400
Data Bits 5, 6, 7, 8
Flow Control None, RTS/CTS, X-ON/X-OFF
Mode Selection RS-232/422/485 software-selectable
Parity None, even, odd, mark, space
RS-232 Lines TXD, RXD, RTS, CTS, DTR, DSR, DCD, GND
RS-422 Lines TXDA(-), TXDB(+), RXDA(-), RXDB (+), GND
RS-485 (2-Wire) Data(-), Data(+), GND
RS-485 (4-Wire) TXDA(-), TXDB(+), RXDA(-), RXDB (+), GND
RS-422/485 Biasing Auto 4.7 K-ohm pullups and pulldowns
RS-422/485
Termination
Auto termination with through hole (user supplied)
RS-485 Data
Control
Auto control via MCU
Stop Bits 1, 1.5, 2
