TABLE 1-1. CHASSIS SPECIFICATIONS
SPECIFICATION DESCRIPTION
Number of Slots 14
Compatible Media Converters
LHC210A, LHC211A, LHC212A, LGC210A, LGC211A, LGC212A
Media Supported 10/100/1000BASE-T twisted pair and 10/100/1000BASE-FX fiber optic cable
Connectors Depends on media converters installed
Power
Dual Power supplies included: (1) LHGC-RACK-PS-L and (1) LHGC-RACK-PS-R;
Input: 100-240 VAC, 50/60 Hz, 3.0 A;
Output: 5 VDC, 12 A, 60 W;
Connector: IEC320 C14 on each power supply;
Circuit breaker for overvoltage or short circuit protection
Temperature
Operating: 32 to 122° F (0 to 50° C);
Storage: -4 to 185° F (-20 to +85° C)
Relative Humidity 5 to 95%, noncondensing
Dimensions 3.5” H (2U) x 19” W x 9.1" D (8.9 x 48.2 x 23.1 cm)
Weight 15.4 lb. (7.0 kg)
Mounting Comes with blanks and mounting hardware for 14 converters
TABLE 1-2. MEDIA CONVERTERS SPECIFICATIONS
SPECIFICATION DESCRIPTION
Approvals FCC Class B, CE, RoHS
Standards
LHC210A, LHC211A, LHC212A: 10/100BASE-TX, 100BASE-FX;
LGC210A: LGC211A, LGC212A: 10/100BASE-TX/1000BASE-TX, 1000BASE-FX
Media Supported
10/100/1000BASE-T: CAT5 UTP/STP, max. 328 ft. (100 m);
100/1000BASE-FX
Connectors
All: (1) RJ-45,
LHC210A, LGC210A: (1) SFP slot;
LHC211A, LGC211A: (1) MM SC;
LHC212A, LGC212A: (1) SM SC;
User Controls LHC210A. LHC211A, LHC212A: (2) 4-position DIP switches C210A,
Maximum Distance
LHC210A, LGC210A: Depends on SFP installed;
LHC211A: 1.2 mi. (2 km) over multimode fiber optic cable:
LHC212A: 12.4 mi. (20 km) over single-mode fiber optic cable;
LGC211A: 1640 ft. (500 m) over multimode fiber optic cable;
LGC212A: 6.2 mi. (10 km) over single-mode fiber optic cable
NIC Transmission Rate
LHC210A, LHC211A, LHC212A: 10/100 Mbps, auto MDI/MDI-X;
LGC210A, LGC211A, LGC212A: 10/100/1000 Mbps, auto MDI/MDI-X
Optical Port Transmission Rate
LHC210A, LHC211A, LHC212A: 100 Mbps;
LGC210A, LGC211A, LGC212A: 1000 Mbps
Optical Connector Wavelength
LHC210A, LGC210A: Depends on SFP installed;
LHC211A, LHC212A, LGC212A; 1310 nm:
LGC211A: 850 nm
Power
All: 5 VDC;
LHC210A, LHC211A, LHC212A: <1 W;
LGC210A, LGC211A, LGC212A: <3 W
Temperature
Operating: 32 to 122° F (0 to 50° C);
Storage: -4 to 158° F (-20 to +70° C)
Relative Humidity 5 to 90%, noncondensing
Dimensions Each unit: 1" H x 3.7" W x 2.7" D (2.5 x 9.4 x 6.9 cm)
