Chapter 1: Specifications
1. Specifications
Data Rates 10/100/1000 and 10G Ethernet
NOTE: Switch ports are transparent to data rates, formats, and protocols.
Output Status Relay Contact
Rating
30 VDC, 1 A maximum (resistive)
Remote Contol Inputs External dry contact not to exceed 100 ohms resistance, including cable
Switching Durablility 1,000,000 operations
Switching Load Additional 65 mA DC,
Additional 20 mA (AC RMS)
NOTE: The switching load is applied for approximately 0.15 seconds during switching.
Connectors SW1040A:
A/B Switch Ports: (3) RJ-45 CAT6,
Remote Control Status Port: (1) 6-position pluggable Phoenix terminal block,
Power: (1) 3.5-mm power input;
SW1041A:
A/B Switch Ports: (3) RJ-45 CAT6,
Ethernet Control Port: (1) RJ-45,
Serial Control Port: (1) DB9 F,
Remote Control Status Port: (1) 6-position pluggable Phoenix terminal block,
Power: (1) 3.5-mm power input
Indicators (2) Switch Position LEDs (A and B),
(1) Command Status LED
Power 100–240 VAC, 50/60-Hz wallmount power supply, 12-VDC output
Environmental Temperature Tolerance:
Operating: 32 to 104° F (0 to 40° C),
Storage: -4 to 158° F (-20 to 70° C)
Humidity Tolerance: Up to 95%, noncondensing
Altitude: Up to 10,000 ft. (3048 m)
Dimensions 2.5"H x 6.25"W x 8.1"D (6.4 x 15.9 x 20.6 cm)
Weight 4 lb. (1.8 kg), including power supply
