1
Body (1 piece)
2
Griddle top and hood (1 piece)
3
Stabilizing shelf (1 piece)
4
Logo panel (1 piece)
5
Hood handle (1 piece)
6
Side shelves
(2 pieces)
7
Side shelf rails
(2 pieces)
8
Control knobs
(2 pieces)
9
Grease cup
(1 piece)
10
Shelf basket
(1 piece)
11
LPG hook
(1 piece)
12
LPG support
(1 piece)
13
Wheels
(2 pieces)
14
Hardware pack (1 piece)
a. M6x12 bolts (8 pieces)
b. M5x24 shoulder bolts (4 pieces)
c. Shear pin (1 piece)
d. Cotter pin (1 piece)
e. Small thumb screws (2 pieces)
f. Wing nuts (6 pieces)
g. Shelf hooks (6 pieces)
h. Large thumb screw (1 piece)
i. Medium thumb screw (1 piece)
j. Slotted washers (6 pieces)
k. Washers (6 pieces)
l. M5 nuts (4 pieces)
[e.][a.]
[k.]
[g.]
[c.]
[d.]
[b.]
[l.]
[j.]
[h.]
[i.]
[f.]

