SERVSWITCH™ SPECTRA
Panel Label Component Description
(Monitor) HD15 F Plug your monitor’s video
cable into this port.
(Video HD15 F Run cable from CPU 1’s
from CPU 1) video-output port to this ports.
(Video HD15 F Run cable from CPU 2’s
from CPU 2) video-output port to this port.
(Keybd.) 6-pin mini- User area: Plug your
keyboard into this port.
DIN F Each CPU area: Run cable
from the CPU’s keyboard
port to this port.
(Mouse) 6-pin mini- User side: Plug your mouse
into this port.
DIN F Each CPU area: Run cable
from the CPU’s mouse
port to this port.
(Audio) 3.5-mm User side: Plug your speakers
stereo F or headphones into
this port.
Each CPU area: Run cable
from the CPU’s audio-
output port to this port.
