BLACKHAWK! PL10C - Circuit Board Connections

________________________________________PL10C / PL20B_____________________________________
22
CIRCUIT BOARD CONNECTION
Connector for control panel buttons
SBQ emergency stop
Ascent SBS
Descent SBD
Remote control
Not connected
Power supply
– 24V AC
ORANGE ORANGE RED RED
RED RED BROWN BLUE Y/G RED RED
BROWN BLUE BROWN BLUE BLACK GREY BROWN BLUE BLACK GREY
BROWN BLUE
ELECTROVALVE DESCENT ELECTROVALVEASCENT ELECTROVALVE ASCENT LIMIT SWITCH ASCENT SQS LIMIT SWITCH ASCENT SQS
