________________________________________PL10C / PL20B_____________________________________
29
ITEM
REFERENCE
DESCRIPTION
QUANTITY
1
S950A905
BASE
1
2
S950A906
INTERNAL SCISSOR
1
2A ▲▲
S950A961
INTERNAL SCISSOR
1
3
S950A907
EXTERNAL SCISSOR
1
3A ▲▲
S950A962
EXTERNAL SCISSOR
1
4
S001A069
TOP PLATE WELDMENT
1
4A
S001A097
TOP PLATE WELDMENT (FROM SERIAL NB 101219)
1
5
S061A191
ARM PIN – RAM / EXTERNAL SCISSOR
1
6
S061A127
ARM PIN – TOP PLATE
2
7
S061A128
ARM PIN – BASE / INTERNAL SCISSOR
2
8
S030A054
CYLINDER – WITH PARACHUTE
1
9
S061A129
SCISSORS COUPLING PIN
1
10
S061A192
ARM PIN – RAM / INTERNAL SCISSOR
1
11
S061A131
LEVERS COUPLING PIN
2
12
S950A642
SWIVEL ARM
4
13
S950A890
BRACKET
4
14
S061A134
RAM UPPER PIN
2
15
S281A013
LEVER ROLLER
4
16
S950A641
RUBBER BLOCK SUPPORT
4
17
MQAC1025
RETAINING RING D=25
8
18
S046A053
PAD SUPPORT
4
19
S061A189
ARM PIN
4
20
S061A132
LOCKING PIN
4
21
MQOC1240
RETAINING RING D=24
4
22
S350A015
CAM FOR LIMIT SWITCH
2
23
S107A015
SELF LUBRICATING BUSHING D25x15
8
24
MABF615
SCREW M6x10
4
25
MHAC615
SCREW M6x10
4
26
S036A022
SELF LUBRICATING BUSHING D30x30
4
27
S107A016
SELF LUBRICATING BUSHING D30x20
4
28
S107A017
SELF LUBRICATING BUSHING D35x20
4
30
MWAE1060
FLAT WASHER M6
4
31
S046A052
NYLON PAD FOR BASE
2
32
S157A006
ARM LEVER P1
2
33█
S046A118
NYLON PAD FOR TOP PLATE
2
34
S157A005
RAM LEVER
2
35
S410A147
LIMIT SWITCH FF4515-10.5DN & CABLE
2
36*
S190A043
PARACHUTE VALVE 1/4G
1
37
S046A054
RUBBER PAD
4
38
MBAF615
SCREW HSHC M6x10
2
39
S646A137
HYDRAULIC HOSE 9M
1
40
S646A138
HYDRAULIC HOSE 6M50
1
41
S410A148
CONNECTOR 10 POLES
1
42
MNDF1100
NUT M10
4
43
S064A217
BLACKHAWK DECAL
1
44
MBEF619
SCREW M6x20
4
45
S057A001
SPRING PIN
4
46
S101A828
HOSE PROTECTIVE PLATE
3
47
S242A026
ANCHOR BOLT
6
48
S900A795
PAD ASS’Y – COMPLETE
4
49
---
S/Nr PLATE
1
