22” to 36”
Page 10
INSTALLATION & ASSEMBLY
Some assembly is required for your new air conditioner. Please read and follow
these instructions carefully.
1. This air conditioner is designed
to be installed in a standard
double-hung window with a
window width between 23”
and 36” (584mm - 914mm).
2. The air conditioner can be
installed without the accordion
panels to fit in a narrow
window opening. See the
window dimensions.
3. The lower sash (the lower part of the window that moves up and down) must allow
for 14.5” of vertical clearance when open. (See Fig. 1)
4. All supporting parts must be secured to firm wood, masonry or metal.
5. The electrical outlet must be within reach of the power cord.
NOTE: Save the product packaging and installation instructions for future reference.
Store the air conditioner in the product box when not in use for an extended
amount of time.
SET UP & USE
Fig. 1
